VG-861　PCI Bus-compatible Programmable Video Signal Generator

Signals up to 250 MHz, Analog / Digital compatible Signal Generator Designed to Interoperate with a Computer

The VG-861 is a PCI bus board type video signal generator for analog / digital output.
A maximum 250 MHz dot clock is realized at low cost. The board contains control and management software for Microsoft Windows, and features that can be used to edit timing and patterns, to create user patterns via GUI, and to display a natural picture (bitmap, JPEG). It is ideal for use with various measuring instruments or automatically operated machinery, and for saving space on the production line.
　

･Features

･Supports analog / digital output.
･Dot clock 250MHz, frequency setting accuracy to 1 dot (2-dot for digital output).
･The standard software allows easy editing, registering and executing of programs.
･Flexibility of editing patterns is dramatically improved. Desired precision patterns can be created by users.
･Using a PCI bus makes installation simpler than products with an ISA bus.
